Ultra Marine doesn’t compromise on quality or design, and neither should you.

Hand-made from 316 stainless steel and hand polished. Ultra Anchors demonstrate the importance of correct weight distribution and design when setting and recovering an anchor. In fact, invert any Ultra Anchor and it will instantly recover itself to the attack position. Such performance has been achieved thanks to the innovative patented features displayed below. Each Anchor is easily recoverable due to the flat pivot surface on the underside base.
Ultra Anchors are suitable for all vessel types and can be securely located on the bow roller. Standard anchor sizes range from 5 kg to 360 kg (larger anchors on request). Using Europe’s best materials and fabricated by specialist engineers, Ultra Anchors are supplied with a lifetime warranty against manufacturing defects under normal conditions and use.

UNIQUE FEATURES

Hollow Shank: Enables weight to be concentrated on anchor tip.
Tubular Construction: Anchor cannot lie on its spine and recovers instantly to the attack position. Anchor will also load correctly into the bow roller.
Lead Filled Tip: Lead is inserted into the anchor tip, achieving the optimal weight distribution and ensuring the anchor will penetrate unfavourable bottom conditions.
Scratch-Catch Point: Especially, it is positioned at bottom. It prevents dragging and provides instant set when anchor moves.
Curved Tip: Importantly, the anchor tip is shaped downwards, ensuring a continuous setting under unfavourable weather conditions. Its angles on the other hand let it help anchor instant set even the anchor is not at the right attack position.
Max Holding Power Base: The concaved base/fluke has the appearance of a shovel and has extreme holding power with a grater surface area than conventional style anchors. The result is more secure, higher holding power anchor that will not release.
Reinforced Eye: Even under the most extreme load the shank’s reinforced eye will not bend, break or fail.
Flat Underside: Once you begin to recover the anchor from the sea floor, it pivots itself on the flat section and begins to release (boat should be directly over anchor).
Side Wing Plates: The ULTRAnchor does not release in a changing wind or tide, it performs a complete 180 degree rotation (while still buried) on its own length and holds firm. On the other hand, it helps easy transport and a continuous geometry on bow rollers.
Non Chain-Foul Bar: Often chain can foul around the shank of the anchor, resulting in the anchor not able to set. The clever design features of the non chain-foul bar ensures chain simply cannot wrap around the shank and provides the ability to attach a trip line. On the other hand, it helps easy transport and a continuous anchor geometry on bow rollers.
Anchor Weight Detail: The anchor weight is stamped into the shank and identifies the anchor size in both kg’s and Ibs.
Serial Number: Every ULTRAnchor is stamped with a unique serial number, ensuring your anchor is always identifiable.

Ultra Marine Anchor Specification
Recommended UM anchor weight		SAILBOAT			POWERBOAT					CATAMARAN					Recommended DIN766 chain diameter	Recommended swivel
		MONO–HULL			HIGH PROFILE			LOW PROFILE		SAIL			POWER
		BOAT WEIGHT	BOAT LENGTH		BOAT WEIGHT	BOAT LENGTH		BOAT LENGTH		BOAT WEIGHT	BOAT LENGTH		BOAT LENGTH
kg	ibs	ton	m	feet	ton	m	feet	m	feet	ton	m	feet	m	feet	mm	#
5	11	1	5	7	1.1	5.2	17	5.7	19	0.7	4.3	14	4.6	15	5	UFS 06
8	18	2	7	23	2.2	7.2	24	7.9	26	1.4	6.1	20	6.4	21	6	UFS 06
12	26	3.8	9	30	4.2	9.3	31	10.2	33	2.7	7.8	26	8.2	27	6	UFS 06
16	35	6.3	10.8	35	6.9	11.1	36	12.2	40	4.5	9.3	31	9.8	32	6-8	UFS 08
21	46	10.2	12.6	41	11.2	13	43	14.3	47	7.3	10.9	36	11.5	38	8	UFS 08
27	60	14.6	14.3	47	16	14.7	48	16.2	53	10.5	12.4	41	13	43	8-10	UFS 10
35	77	21.5	16	52	23.5	16.5	54	18.2	60	15.6	13.8	45	14.6	48	10	UFS 10
45	100	30	17.8	58	32.9	18.3	60	20.1	66	21.6	15.4	51	16.2	53	10-12	UFS 13
60	132	43	20	66	47.1	20.6	68	22.7	74	31	17.3	58	18.2	60	12-13	UFS 13
80	176	63	22.3	73	69	23	75	25.3	83	45.4	19.3	63	20.3	67	13	UFS 16
100	220	85	24.5	80	93	25.2	83	27.7	91	61	21.2	70	22.3	73	14	UFS 16
130	290	123	27.4	90	135	28.2	93	31	102	89	23.7	78	25	82	14-16	UFS 20
160	350	174	30.4	100	191	31.3	103	34.4	113	125	26.3	86	27.7	91	16	UFS 20
200	440	262	34.4	113	287	35.4	116	39	128	190	29.8	98	31.3	103	18	UFS 20
250	550	400	39.2	129	438	40.4	133	44.4	146	290	33.9	111	35.7	117	18-20	UFS 26
300	660	550	44	144	600	45.3	149	49.8	163	400	38.1	125	40	131	20	UFS 26
360	800	760	50	164	830	51.5	169	56.7	186	550	43.3	142	45.5	150	22	UFS 26
